AI Principles · Hardware

Why AI needs GPUs

A neural network is, underneath, one operation repeated trillions of times: matrix multiplication. GPUs win because they do that one thing with thousands of cores at once — while a CPU, built for a few fast sequential tasks, does it a handful at a time.

Read at your depth: 01 The answer · 02 Intuition · 03 Mechanics · 04 The math · 05 The code · 07 Sources

01The answer, then the intuition

The same sum, a million times over

Strip a transformer down and almost all of its work is multiplying big grids of numbers — every attention step and every weight layer is a matrix multiply. And a matrix multiply is embarrassingly parallel: each output number is an independent dot product that doesn't depend on the others, so in principle you could compute all of them at the same time.

A CPU has a few very powerful cores tuned for fast, branchy, sequential work. A GPU has thousands of simpler cores built to run the exact same arithmetic on many numbers at once — plus huge memory bandwidth to feed them. For AI's one repeated operation, that's a perfect match. Race them on the same matrix multiply:

CPU vs GPU — the same matrix multiply

Illustrative. Each tile is a chunk of output; cores fill tiles in parallel. The animation shows the shape of the gap — the real number is in the readout.

CPU~8 cores · sequential

progress0%

GPUthousands of cores · parallel

progress0%

Same math. One finishes while the other is barely started.

02Mechanics

Built for throughput, not latency

Thousands of cores. A modern GPU has tens of thousands of arithmetic units running the same instruction across different data at once (SIMT). For one operation repeated over millions of numbers, that's ideal; for tangled, branchy logic, it's wasted.
Tensor cores. GPUs now include dedicated units that do a small matrix multiply-accumulate in a single step — hardware built specifically for the one operation neural networks need. This is most of where the headline FLOP/s comes from.
Memory bandwidth. All those cores are useless if you can't feed them. GPUs pair the compute with very fast high-bandwidth memory (HBM) — the subject of the next chapter — so weights and activations stream in fast enough to keep the cores busy.
The trade-off. A CPU minimizes the time for one task (latency); a GPU maximizes the total work done across many (throughput). AI is almost entirely the second kind of problem, which is why the GPU — originally built to shade millions of pixels in parallel — turned out to be the perfect AI chip by accident.

This is also why the field is a hardware story as much as a software one: progress is gated by how many parallel multiply-adds per second per dollar the silicon can deliver.

04The math

expand ▾

Why the gap is ~2,000×

Multiplying two $d \times d$ matrices produces $d^2$ outputs, each a dot product of length $d$ (a multiply and an add per term), so the cost is:

$$ \text{FLOPs} = 2\,d^3 $$

Wall-clock time is just that divided by the hardware's throughput. For $d = 8192$ that's about $1.1 \times 10^{12}$ FLOPs. A CPU delivering ~0.5 TFLOP/s of usable fp32 takes seconds; a GPU's tensor cores deliver on the order of ~1,000 TFLOP/s:

$$ t = \frac{2\,d^3}{\text{throughput}} \;\Rightarrow\; t_{\text{CPU}} \approx 2.2\ \text{s}, \quad t_{\text{GPU}} \approx 1.1\ \text{ms} $$

A roughly 2,000× difference on a single operation — and a model is billions of these. The gap isn't that the GPU's individual cores are faster (they're slower); it's that there are thousands of them doing independent work at once. Parallelism, not clock speed, is the whole game.

05The code

expand ▾

The race, in numbers

One large matrix multiply, timed against a CPU's and a GPU's throughput.

cpu_vs_gpu.py

def matmul_flops(d):
    return 2 * d**3            # d^2 outputs, each a length-d dot product

d = 8192
flops = matmul_flops(d)

cpu = 0.5e12     # CPU: ~0.5 TFLOP/s usable fp32
gpu = 990e12     # GPU tensor cores: ~990 TFLOP/s bf16 (H100-class)

print(f"{d}x{d} matmul: {flops:.2e} FLOPs")
print(f"CPU: {flops/cpu:.3f} s")
print(f"GPU: {flops/gpu*1000:.3f} ms")
print(f"speedup: {(flops/cpu)/(flops/gpu):.0f}x")
# 8192x8192 matmul: 1.10e+12 FLOPs
# CPU: 2.199 s
# GPU: 1.111 ms
# speedup: 1980x

07Going deeper

expand ▾

The primary sources

NVIDIA — GPU Performance Background · cores, throughput, and the roofline.
NVIDIA — Tensor Core architecture · the matrix-multiply-accumulate unit.
Dao et al. (2022) — FlashAttention · why memory movement, not FLOPs, often dominates.
SemiAnalysis · ongoing economic analysis of the AI hardware supply chain.
