AI Principles · Infrastructure

Latency, throughput, tokens/sec

How fast is an AI model? The honest answer is a formula. Because decode is memory-bound, a model's speed is set by how fast it can stream its weights out of memory — tokens per second ≈ bandwidth ÷ model bytes.

Read at your depth: 01 The answer · 02 Intuition · 03 Mechanics · 04 The math · 05 The code · 07 Sources

01The answer, then the intuition

Speed is bandwidth divided by size

You felt this in the last chapter: decode writes one token per forward pass, and each pass has to read the entire model out of memory. So the speed limit isn't how fast the GPU can compute — it's how fast it can move the weights. A bigger model means more bytes to stream per token, which means fewer tokens per second. It's almost that simple.

Two numbers matter to a user: time to first token (how long until the answer starts — set by prefill) and tokens per second (how fast it then types — set by decode). The calculator below computes the second from first principles. Pick a model size and drag the precision; watch a 70B model crawl, and watch quantization nearly quadruple it:

Tokens/sec calculator — the memory-bound speed limit

Single stream on one GPU with ~3.35 TB/s memory bandwidth (H100-class). tok/s ≈ bandwidth ÷ (params × bytes).

—

decode tokens / sec

—

time for a 1,000-token reply

—

bytes streamed / token

precision16-bit

16-bit8-bit4-bit

02Mechanics

Latency, throughput, and the tension between them

Time to first token (TTFT). Set by prefill — how long to process your whole prompt before the first word appears. Grows with prompt length; this is the "thinking…" pause.
Inter-token latency / tokens-per-second. Set by decode. Each token streams the model's weights from memory, so per-user speed ≈ memory bandwidth ÷ model bytes. This is the steady typing rate you watch.
End-to-end latency. Simply TTFT + (tokens × per-token time). A long answer from a big model is slow on both counts.
Throughput. The system's total tokens/sec across all users at once. Here's the twist: because one user's decode barely uses the GPU's compute, you can run many users' requests in the same forward pass — batching — and total throughput climbs almost for free, even though each individual user's speed is unchanged or slightly slower.
The tension. Latency is one user's experience; throughput is the system's efficiency. Bigger batches raise throughput (and lower cost per token) but can raise latency. Tuning that trade-off is the central job of an inference team.

So "tokens per second" is two metrics wearing one name: a per-user speed bounded by bandwidth, and an aggregate throughput bounded by compute once the batch is full. Quantization helps the first; batching helps the second.

04The math

expand ▾

The roofline of decode

Each decode step streams roughly the whole model — $N$ parameters at $b/8$ bytes each — from memory. With memory bandwidth $\text{BW}$ (bytes/sec), the time per token and the rate are:

$$ t_{\text{token}} \approx \frac{N \cdot (b/8)}{\text{BW}}, \qquad \text{tokens/sec} \approx \frac{\text{BW}}{N \cdot (b/8)} $$

End-to-end latency for a prompt of $P$ and an answer of $G$ tokens:

$$ \text{latency} \approx \underbrace{t_{\text{prefill}}(P)}_{\text{TTFT}} \;+\; G \cdot t_{\text{token}} $$

The roofline idea: decode lives on the memory-bandwidth slope, so halving the bytes (quantize) roughly doubles the rate. Batching $B$ requests reuses the same weight-load across all of them, so aggregate throughput rises toward $B \times$ — until the work becomes compute-bound and hits the GPU's FLOPs ceiling instead. Inference engineering is the art of climbing that roofline.

05The code

expand ▾

Speed, from the bandwidth up

Single-stream decode rate for three model sizes at three precisions, on an H100-class GPU.

tokens_per_sec.py

BW = 3.35e12   # H100 HBM3 memory bandwidth, ~3.35 TB/s

def toks_per_sec(N, bits):
    bytes_streamed = N * (bits / 8)     # ~whole model moved per token
    return BW / bytes_streamed

for N, nm in [(7e9,"7B"), (70e9,"70B"), (175e9,"175B")]:
    rates = "   ".join(f"{b}-bit {toks_per_sec(N,b):5.1f}" for b in [16,8,4])
    print(f"{nm:5s}: {rates}  tok/s")
# 7B   : 16-bit 239.3   8-bit 478.6   4-bit 957.1  tok/s
# 70B  : 16-bit  23.9   8-bit  47.9   4-bit  95.7  tok/s
# 175B : 16-bit   9.6   8-bit  19.1   4-bit  38.3  tok/s

print(f"70B 16-bit, 1000-token reply: {1000/toks_per_sec(70e9,16):.1f} s")  # 41.8 s

07Going deeper

expand ▾

The primary sources

Pope et al. (2022) — Efficiently Scaling Transformer Inference · latency vs throughput trade-offs.
Databricks — LLM Inference Performance Engineering · TTFT, tokens/sec, batching in practice.
NVIDIA — GPU Performance Background (roofline) · memory-bound vs compute-bound.
MLPerf Inference · the standard latency/throughput benchmark.
